Solid copper core PVC insulation and sheathing and TC braided shield control cable
1.Product Standards
GB/T 9330.1-2008 GB/T9330.2-2008 GB/T 19666-2005
2.Product use
Laying indoors, cable ditch, pipelines and other requirements of the shielding occasions
3.use characteristics
3.1 The conductor of the cable is the maximum operating temperature of 70.
3.2 Ambient temperature is not less than 0℃
3.3 Cable flame retardant properties meet the requirements of the corresponding indicators in the
GB/T19666-2005 standard.
4.Modle
kvvp1
5.Cable structure size
| Nominal Aluminum(mm2) |
Insulation thickness(mm) |
shielding copper wire diameter (mm) |
sheath thickness (mm) |
cable outside diameter(mm) |
cable weight(kg/km) |
| 2x0.75 |
0.6 |
0.15 |
1.2 |
8.1 |
94 |
| 2x1 |
0.6 |
0.15 |
1.2 |
8.4 |
101 |
| 2x1.5 |
0.7 |
0.15 |
1.2 |
9.3 |
124 |
| 2x2.5 |
0.8 |
0.15 |
1.2 |
10.5 |
159 |
| 2x4 |
0.8 |
0.20 |
1.2 |
11.7 |
214 |
The above parameters are only part of the parameters, for reference only.
FAQ
Q1. Can I have a sample order for cable?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production needs 2-3 weeks .
Q3. Do you have any MOQ limit for cable?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for yolarlink cable?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 1 year warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new cable with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution i
ncluding re-call according to real situation.
